AT27C256R-15JC

256K OTP EPROM, DIP, PLCC, SOIC, TSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.60~0.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.60~0.80

PartNumber:: AT27C256R-15JC

Brand:: ATMEL Corporation - ATMEL | Pack: PLCC | D/C: 96+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Carol's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-03-29

From Other Seller

Part Number:AT27C256R-15JC
US $0.60 - 0.80
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT27C256R-15JC is a low-power, high-performance 262,144-bit one-time programmable read-only memory (OTP EPROM) organized 32K by 8 bits. It requires only one 5V power supply in normal read mode operation. Any byte can be accessed in less than 45 ns, eliminating the need for speed reducing WAIT states on high-performance microprocessor systems. The AT27C256R-15JC is available in a choice of industry-standard JEDEC-approved one time programmable (OTP) plastic DIP, PLCC, SOIC, and TSOP packages. All devicesfeature two-line control (CE, OE) to give designers the flexibility to prevent bus contention.

Parametrics

Absolute Maximum Ratings: (1)Temperature Under Bias: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground: -2.0V to +7.0V; (4)Voltage on A9 with Respect to Ground: -2.0V to +14.0V; (5)VPP Supply Voltage with Respect to Ground: -2.0V to +14.0V; (6)VIH, Input High Voltage: 2.0 to VCC + 0.5 V.

Features

Features: (1)Fast Read Access Time – 45 ns; (2)Low-Power CMOS Operation: 100 μA Max Standby; 20 mA Max Active at 5 MHz; (3)JEDEC Standard Packages: 28-lead PDIP; 32-lead PLCC; 28-lead TSOP and SOIC; (4)5V ± 10% Supply; (5)High Reliability CMOS Technology: 2,000V ESD Protection; 200 mA Latchup Immunity; (6)Rapid Programming Algorithm – 100 μs/Byte (Typical); (7)CMOS and TTL Compatible Inputs and Outputs; (8)Integrated Product Identification Code; (9)Industrial and Automotive Temperature Ranges; (10)Green (Pb/Halide-free) Packaging Option.
