MAX1566ETL+T

Six-Channel, High-Efficiency, Digital Camera Power Supplies, QFN40, 95% Efficient Converter

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~1.10 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.50~1.10

PartNumber:: MAX1566ETL+T

Brand:: Maxim Integrated Products - Maxim | Pack: QFN | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Carol's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-18

From Other Seller

Part Number:MAX1566ETL+T
US $0.50 - 1.10
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX1566ETL+T provides a complete powersupply solution for digital cameras. MAX1566ETL+T improves performance, component count, and size compared to conventional multichannel controllers in 2-cell AA, 1-cell lithium-ion (Li+), and dual-battery designs. On-chip MOSFETs provide up to 95% efficiency for critical power supplies, while additional channels operate with external FETs for optimum design flexibility. This optimizes overall efficiency and cost, while also reducing board space.

Parametrics

MAX1566ETL+T absolute maximum ratings: (1)PV, PVSU, SDOK, AUX1OK, SCF, ON_, FB_, SUSD to GND: -0.3V to +6V; (2)PG_ to GND: -0.3V to +0.3V; (3)DL1, DL3, INDL2, PVM, PVSD to GND: -0.3V to (PVSU + 0.3V); (4)DL2 to GND: -0.3V to (INDL2 + 0.3V); (5)LXSU Current: 3.6A; (6)LXM Current: 3.6A; (7)LXSD Current: 2.25A; (8)REF, OSC, CC_ to GND: -0.3V to (PVSU + 0.3V); (9)Continuous Power Dissipation (TA = +70℃): 2105mW; (10)Operating Temperature Range: -40℃ to +85℃; (11)Junction Temperature: +150℃; (12)Storage Temperature Range: -65℃ to +150℃; (13)Lead Temperature (soldering, 10s): +300℃.

Features

MAX1566ETL+T features: (1)95% Efficient Step-Up DC-to-DC Converter; (2)0.7V Minimum Input Voltage; (3)Main DC-to-DC Configurable as Either Step-Up or Step-Down; (4)Combine Step-Up and Step-Down for 90% Efficient Boost-Buck; (5)95% Efficient Step-Down for DSP Core; (6)Regulate LED Current for Four, Six, or More LEDs; (7)Open LED Overvoltage Protection; (8)Transformerless Inverting Controller (MAX1567); (9)Three Extra PWM Controllers (Two on the MAX1567); (10)Up to 1MHz Operating Frequency; (11)1μA Shutdown Mode; (12)Soft-Start and Overload Protection; (13)Compact 40-Pin 6mm x 6mm Thin QFN Package.
